BrandAMD
GenerationRyzen 9000 Series
Cores16 Cores
Threads32 Threads
Graphic ( IGPU )NO Graphics ( Need Graphic Card )
CPU SocketAM5
Processor ArchitectureZen 5
Form FactorDesktop (Tray Processor Only)
System Memory Type ( RAM )DDR5
NVMe SupportGen5
PROCESSOR MODELRYZEN 9
Model / SeriesRYZEN 9 9950X3D
Base Clock Speed4.3 GHz
Max Boost Clock Speed5.7 GHz
Supported ChipsetsA620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850
Multithreading (Hyper-Threading) SMTYES
L1 Cache1,280 KB
L2 Cache16MB
L3 Cache128MB
Default Thermal Design Power (TDP)170 W
PCI Express VersionPCI 5.0
Memory Channels2
Maximum Memory256GB
Max Memory Speed5600MHZ
ECC SupportYES
AMD EXPO™ Memory Overclocking TechnologyYES
Precision Boost OverdriveYES
Curve Optimizer Voltage OffsetsYES
AMD Ryzen™ Master SupportYES
AMD SmartAccess MemoryYES
Virtualization Technology (VT-x / VT-d)AMD‑V supported; IOMMU/AMD‑Vi depends on motherboard and BIOS
Max Operating Temperature95°C
Native USB 3.2 Gen 2 2 (10Gbps) Ports4
Native USB 2.0 (480Mbps) Ports1
Graphics ModelAMD Radeon Graphics
Graphics Frequency2,200 MHz / 2 cores
DisplayPort™ VersionDisplayPort output over USB‑C Alt Mode; physical ports and supported version depend on the motherboard
NVMe Storage SupportBOOT / RAID 0/1/5/10
OSWIN11 / LINUX
Warranty3Y WARRANTY
