BrandAMD
GenerationRyzen 7000 Series
Cores8 Cores
Threads16 Threads
Graphic ( IGPU )Intergrated Graphic Support
CPU SocketAM5
Processor ArchitectureZen 4
Form FactorDesktop (Tray Processor Only)
System Memory Type ( RAM )DDR5
NVMe SupportGen5
PROCESSOR MODELRYZEN 7
Model / SeriesRyzen 7 7800X3D / Ryzen 7000 Series
Base Clock Speed4.2 GHz
Max Boost Clock Speed5.0 GHz
Multithreading (Hyper-Threading) SMTYES
L1 Cache512 KB
L2 Cache8 MB
L3 Cache96 MB
Default Thermal Design Power (TDP)120 W
Supported ChipsetsA620, X670E, X670, B650E, B650, X870E, X870, B840, B850
PCI Express VersionPCIe 5.0
PCIe Configurations28 total / 24 usable CPU lanes
Memory Channels2
Maximum Memory128GB
Max Memory SpeedDDR5-5200 with 2 DIMMs; up to DDR5-3600 with 4 DIMMs
ECC SupportYES
AMD EXPO™ Memory Overclocking TechnologyYES
Precision Boost OverdriveYES
Curve Optimizer Voltage OffsetsYES
AMD Ryzen™ Master SupportYES
AMD SmartAccess MemorySupported with compatible Radeon graphics card, motherboard, and driver
Intel® Hyper-Threading TechnologyAMD SMT is supported
DisplayPort ExtensionsUSB-C DisplayPort Alt Mode supported; port availability depends on motherboard
Virtualization Technology (VT-x / VT-d)AMD-V supported
Max Operating Temperature89°C
Native USB 3.2 Gen 2 2 (10Gbps) Ports4
Native USB 2.0 (480Mbps) Ports1
Graphics ModelAMD Radeon™ Graphics
Graphics Frequency2200 MHz
Graphics Core Count2
DirectX® VersionDepends on graphics driver
DisplayPort™ VersionDepends on graphics driver
NVMe Storage SupportRAID 0/1/10; PCIe 5.0
OSWIN 11 / LINUX
Warranty3Y WARRANTY
