BrandAMD
GenerationRyzen 8000 Series
Cores6 Cores
Threads12 Threads
Graphic ( IGPU )Intergrated Graphic Support
CPU SocketAM5
Processor ArchitectureZen 4
Form FactorDesktop (Tray Processor Only)
System Memory Type ( RAM )DDR5
NVMe SupportGen4
Model / SeriesRyzen 5 8600G
Base Clock Speed4.3 GHz
Max Boost Clock Speed5.0 GHz
Multithreading (Hyper-Threading) SMTYES
L1 Cache384 KB
L2 Cache6 MB
L3 Cache16 MB
Default Thermal Design Power (TDP)65 W
Configurable TDP (cTDP)45–65 W
Supported ChipsetsA620, B650, B650E, B840, B850, X670, X670E, X870, X870E
PCI Express VersionPCIe 4.0
PCIe Configurations20 lanes total, 16 usable; motherboard determines slot layout
Memory Channels2
Maximum Memory256GB
Max Memory SpeedDDR5-5200MHZ
AMD EXPO™ Memory Overclocking TechnologyYES
Precision Boost OverdriveYES
Curve Optimizer Voltage OffsetsYES
AMD Ryzen™ Master SupportYES
AMD SmartAccess MemoryAvailable with compatible graphics, motherboard, and BIOS
Virtualization Technology (VT-x / VT-d)AMD‑V supported; IOMMU depends on platform suppor
Max Operating Temperature95°C
Native USB 4 (40Gbps) Ports2
Native USB 3.2 Gen 2 2 (10Gbps) Ports2
Native USB 2.0 (480Mbps) Ports1
Graphics ModelRadeon 760M
Graphics Frequency2,800 MHz
Graphics Core Count8 cores
DirectX® VersionDirectX 12
DisplayPort™ VersionDisplayPort 2.1
NVMe Storage SupportRAID 0/1; PCIe 4.0
OSWIN 11 / LINUX
Warranty3Y WARRANTY
