BrandAMD
GenerationRyzen 7000 Series
Cores6 Cores
Threads12 Threads
Graphic ( IGPU )NO Graphics ( Need Graphic Card )
CPU SocketAM5
Processor ArchitectureZen 4
Form FactorDesktop (Tray Processor Only)
System Memory Type ( RAM )DDR5
NVMe SupportGen5
Model / SeriesRyzen 5 7500F
Base Clock Speed3.7 GHz
Max Boost Clock Speed5.0 GHz
Multithreading (Hyper-Threading) SMTYES
L1 Cache384 KB
L2 Cache6 MB
L3 Cache32 MB
Default Thermal Design Power (TDP)65 W
Supported ChipsetsA620, B650, B650E, B840, B850, X670, X670E, X870, X870E
PCI Express VersionPCIe 5.0
PCIe Configurations28 lanes total, 24 usable; motherboard determines slot layout
Memory Channels2
Maximum Memory128GB
Max Memory SpeedDDR5-5200MHZ
ECC SupportYES
AMD EXPO™ Memory Overclocking TechnologyYES
Precision Boost OverdriveYES
Curve Optimizer Voltage OffsetsYES
AMD Ryzen™ Master SupportYES
AMD SmartAccess MemorySupported with a compatible Radeon GPU, motherboard, and BIOS
Virtualization Technology (VT-x / VT-d)AMD‑V supported; IOMMU depends on motherboard/BIOS
Max Operating Temperature95°C
Native USB 3.2 Gen 2 2 (10Gbps) Ports4
Native USB 2.0 (480Mbps) Ports1
NVMe Storage SupportRAID 0/1/10; PCIe 5.0 NVMe
OSWIN 11 / LINUX
Warranty3Y WARRANTY
