BrandAMD
GenerationRyzen 5000 Series
Cores6 Cores
Threads12 Threads
Graphic ( IGPU )NO Graphics ( Need Graphic Card )
CPU SocketAM4
Processor ArchitectureZen 3
Form FactorDesktop (Tray Processor Only)
System Memory Type ( RAM )DDR4
NVMe SupportGen4
Model / SeriesRyzen 5 5500X3D
Base Clock Speed3.0 GHz
Max Boost Clock Speed4.0 GHz
Multithreading (Hyper-Threading) SMTYES
L1 Cache384 KB
L2 Cache3 MB
L3 Cache96 MB
Default Thermal Design Power (TDP)105 W
Supported ChipsetsX570, X470, X370, B550, B450, B350, A520
PCI Express VersionPCIe 4.0
PCIe Configurations24 lanes total, 20 usable; motherboard determines slot layout
Memory Channels2
Maximum Memory128GB
Max Memory SpeedDDR4-3200MHZ
ECC SupportYES
AMD Ryzen™ Master SupportYES
AMD SmartAccess MemorySupported with compatible Radeon GPU, 500-series motherboard, and BIOS
Virtualization Technology (VT-x / VT-d)AMD‑V supported; IOMMU depends on motherboard/BIOS
Max Operating Temperature90°C
Native USB 3.2 Gen 2 2 (10Gbps) Ports4
NVMe Storage SupportRAID 0/1/10; PCIe 4.0 NVMe
OSWIN 11 / LINUX
Warranty3Y WARRANTY
