BrandAMD
GenerationRyzen 3000 Series
Cores4 Cores
Threads8 Threads
Graphic ( IGPU )Intergrated Graphic Support
CPU SocketAM4
Processor ArchitectureZen+
Form FactorDesktop (Tray Processor Only)
System Memory Type ( RAM )DDR4
NVMe SupportGen3
Model / SeriesRyzen 5 3400G
Base Clock Speed3.7 GHz
Max Boost Clock Speed4.2 GHz
Multithreading (Hyper-Threading) SMTYES
L1 Cache384 KB
L2 Cache2 MB
L3 Cache4 MB
Default Thermal Design Power (TDP)65 W
Configurable TDP (cTDP)45–65 W
Supported ChipsetsX570, X470, X370, B450, B350, A320
PCI Express VersionPCIe 3.0
PCIe Configurations20 lanes total, 16 usable; graphics link up to x8. Motherboard determines slot layout
Memory Channels2
Maximum Memory64GB
Max Memory SpeedDDR4-2933MHZ
ECC SupportYES
AMD Ryzen™ Master SupportYES
Virtualization Technology (VT-x / VT-d)AMD‑V supported; IOMMU depends on motherboard/BIOS
Max Operating Temperature95°C
Graphics ModelRadeon RX Vega 11 Graphics
Graphics Frequency1,400 MHz
Graphics Core Count11 cores
DirectX® VersionDirectX 12
DisplayPort™ VersionAdaptive-Sync, HBR3, HDR Metadata
NVMe Storage SupportRAID 0/1/10; PCIe 3.0
OSWIN11 / LINUX
Warranty1Y WARRANTY
